Kiln · cooler · crushers · mills
Cement plants
The kiln outlet and the clinker cooler are the hardest places a casting works: 1,150 to 1,350 °C clinker, thermal shock every revolution, abrasion all day. We cast grate plates, replaceable lips, nose-ring segments and anchors in heat-resistant stainless, and hammers and liners in manganese steel and high-chrome iron, for plants that would rather keep a stock of patterns in Batangas than a container on the water.
Parts by zone
| Zone | Castings | Alloy |
|---|---|---|
| Kiln outlet | Nose-ring segments and holders, back plates, retainer rings, castable anchors | SCH21 / ACI HH, HK; stainless 310 fasteners |
| Clinker cooler | Grate plates by stage, replaceable lips, side liners, crossbar liners | HK first stage, HH second, HF third; 25/12 cast steel lips |
| Crushers and hammer mills | Hammers, striking bars, impact and shell liners, end-disk liners | Austenitic manganese steel, Cr-Mn steel, high-chrome iron, HARDOX-type plate on request |
| Coal and raw mills | Grinding rollers and table segments, wave plates, nozzles and holders | High-chrome iron 15 to 28% Cr, gray iron for nozzle holders |
Castings to 100 kg each, so a full grate stage is many pieces, not a few big ones; that suits a foundry that pours five heats a shift. Larger single pieces are quoted with a partner foundry.
Working with a plant
- Supplier to Solid Cement Corporation (CEMEX) since 2023: grate plates and replaceable lips, with trial reports on each stage.
- Registered vendor at the CEMEX plants; earlier supply to Northern Cement in 2015.
- Pattern bank: once a plate is drawn and poured, your reorder is a heat away.
- We can help with failure analysis: section, microstructure and hardness of the worn part against the new one, with a written note on cooling rates and expansion joints where that is where the problem lies.
What to send
- Drawing or the worn part, with the stage or position
- Current alloy and service life, and how it fails
- Set size and plant shutdown date
- Inspection and documentation requirements
